MSN-26071
AIRCRAFT LOCATION: Tucson, AZ
RECORDS LOCATION: GECAS
CONDITION OF SALE: "AS IS WHERE IS"
Content
Insurance Requirements and Recommendations
Terms of Use
Aircraft Specification Summary
CFM56-3C1 Engine Specification Summary
Landing Gear Specification Summary
Aircraft and Engine Spec Files
A - Aircraft Certificates
B - Aircraft Maintenance Summaries/a>
C - Aircraft Maintenance Records
D - Configuration Status
F - Engine #1 - 725303
F - Enging #2 - 856344
G - APU
I - Landing Gear Records
INSURANCE REQUIREMENTS AND RECOMMENDATIONS
INSURANCE REQUIREMENT: GECAS requires liability insurance to be in place for 24 months from date of purchase. Please contact Pat Bergin to discuss this requirement if necessary.
RECOMMENDATION: Inspect the Records and Aircraft prior to making an offer
SPECIAL COMMENTS:
Stephen W. Hudson, PMP
817-366-1788 (cell)
steve@aimfleet.com
steve.hudson@gecas.com
TERMS OF USE
The information contained on and within this website is available on a confidential basis only. By entering this website you agree and acknowledge that such information is commercially sensitive and proprietary to Seller, and agree to maintain such information strictly confidential and not to disclose it, except as may be required by applicable law, without the prior written consent of the Seller, to any person other than those acting in direct connection with the potential purchase of the asset(s) listed herein. Such persons shall have been advised of the confidential nature of this information, and of the requirement that it may not be disclosed except in accordance with the terms of this paragraph. Should you have any questions or difficulty with these terms, please contact Pat Bergin
GECAS may withdraw this aircraft from the market at any time at its sole discretion. Any potential transaction for the sale of the listed aircraft is subject to GECAS corporate approvals and all necessary third party consents.
AIRCRAFT SPECIFICATION SUMMARY
Type Aircraft: 737-400 | Total Time: 61,126 |
Registration: VP-BAN | Total Cycles: 31,356 |
Serial Number: 26071 | As of Date: Jun 10, 2015 |
Regulatory Authority: DCA | Manufacture Date: Nov 1992 |
Approach Category: IIIa | Acquisition Date: |
Country Of Registration: Bermuda | Last Check: See Specs |
Configuration: 146Y, 8B | Next Check Due: See Specs |
Max Taxi Gross Weight: 68,265 kgs | Date of Last Weigh: Jan 16, 2013 |
Max Take Of Weight: 68,038 kgs | Max Zero Fuel Weight: 53,070 kgs |
Max Landing Weight: 56,245 kgs |
CFM56-3C1 ENGINE SPECIFICATION SUMMARY
Position | S.N | TSN | TSO | CSN | CSO |
---|---|---|---|---|---|
#1 | 72530331 | 31,319 | 7,708 | 45,608 | 3,382 |
#2 | 856344 | 55,172 | 4,308 | 28,821 | 1,965 |
#1 - Limiter LPT 1, 5,194 cyc - (Serviceable)
#2 - Limiter HPCR, 3,126 cyc (Fan Disk 2,244 cyc) - (Serviceable)
LANDING GEAR SPECIFICATION SUMMARY
Position | S/N | CSO | Last O/H | Due O/H | Notes |
---|---|---|---|---|---|
NLG | T5072P2361 | 3,326 | Feb 24, 2012 | Feb 2022 | 21,000 cyc See Spec |
LMLG | MCO4661P2361 | 3,326 | Feb 24, 2012 | Feb 2022 | 21,000 cyc See Spec |
RMLG | MCO4661P2361 | 3,326 | Feb 24, 2012 | Feb 2022 | 21,000 cyc See Spec |
AIRCRAFT AND ENGINE SPEC FILES
A - Aircraft Certificates
A001 Certificate of Airworthiness & Airworthiness Review Certificate (ARC) (if applicable)
A002 Certificate of Registration
A003 Certificate of Airworthiness for Export (if applicable)
A006 Aircraft De-Registration confirmation (if applicable)
B - Aircraft Maintenance Summaries
B001 Certified current Time in Service (Hours & Cycles) & Maintenance Status
B002 Certified status of airframe & appliance Airworthiness Directives (including method of compliance)
B003 Certified status of Manufacturer Service Bulletins incorporated
B004 Certified status of all Airframe Non-Manufacturer Modifications incorporated (including STC's)
B005 Certified status of supplemental structural inspections (SSI's) (if applicable)
B006 Certified status of CPCP/ISIP Tasks (if applicable)
B007 Certified status of installed Hard Time components (including time, hours and cycles remaining)
B008 Certified statu s of OC/CM Components
B009 Certified status of Airframe Check/Inspection history
B010 Certified list of Deferred Maintenance Items (if applicable)
B011 Certified status of Maintenance Task compliance listing ('Last Done\Next Due') including 'Out of Phase' Inspections
B012 Operator Incident (Clearance) Statement to include Airframe, Engines, Landing Gear & APU covering period of operation
B013 Certified map of structural repairs and allowable damage, including reference to applicable approved data and time limited items
B014 Certified status of Certification Maintenance Requirements (CMR)
B016 Life Limited Parts Status, Airframe Parts (if applicable)
B017 Certified statement of Oil and Fluid types used in Aircraft, Engines and APU
B020 Certified Flight Data Recorder report verifying that required parameters are within approved limits
B021 Operator Maintenance Program Summary
B022 Aircraft Flight Time Report / Aircraft Log Book
C - Aircraft Maintenance Records
C012 Certified Aircraft Weighing Report
C014 Last Demonstration Flight Report and relevant Technical Log
C017 Certified Current Records Inventory (including full inventory of boxes delivered)
D - Configuration Status
D001 Layout of Passenger Accommodation Drawing (LOPA), including Seat Part Numbers
D003 Emergency Equipment Drawing with item description and Part Number
D004 Inventory of Loose and Galley Equipment
D005 Inventory Listing of Avionics Units installed (E & E Bay)
MISC Aircraft Repair Photos
F - Engine #1 - 725303
F001 Certified Statement on Status of Each Engine to include Thrust Statement
F002 Certified Status of Engine Airworthiness Directives including Method of Compliance
F005 Certified Life Limited Parts Listing indicating cycles remaining
F011 Last Borescope Report (including video if available)
Misc Entire Engine Records File (Zip Folder)
F - Engine #2 - 856344
F001 Certified Statement on Status of Each Engine to include Thrust Statement
F002 Certified Status of Engine Airworthiness Directives including Method of Compliance
F005 Certified Life Limited Parts Listing indicating cycles remaining
F011 Last Borescope Report (including video if available)
Misc Entire Engine Records File (Zip Folder)
G - APU
G001 Certified total Time in Service (Hours & Cycles) of APU (including statement of ratio from Aircraft Hrs to APU Hrs)
G002 Certified status of APU Airworthiness Directives including method of compliance
G005 All Historical APU Shop Visit Reports (Zip Folder) - Last Only
Misc Entire APU Records File (Zip Folder)
I - Landing Gear Records
I001 Airworthiness Release Certificate from Last Overhaul (and any subsequent maintenance) for each major Landing Gear Assembly
Nose | LMLG | RMLG
I002 Certified status of Life Limited Parts (LLP's) for each Landing Gear showing Cycles consumed since new and allowable Cycles remaining (No BTB is guaranteed)
Nose | LMLG | RMLG
I003 Maintenance Shop Reports from last overhaul and any subsequent shop maintenance (zip folder)
Nose | LMLG | RMLG
